Multifunction precision 6 row seeder sowing machine
Model No.: 2BYF-6
Application Field: Agriculture
Function: Sowing, Cleaning-stubble ,fertilizing , Seeder
Power Source: Tractor
Mechanization: Automatic Planting Machine
Sowing: Precision Seeder
Certification: CE, ISO9001:2008, SGS, GMP, QS, UL
Working Efficiency: High Efficiency
Packing: Iron Cage
Advantage: High Performance
Warranty: 12 Months
Name: Multifunction Precision Planter
Working Width: 1200~3200mm
Packaging: Strong exporting standard packages. Iron frame ( As your requirements )
Productivity: 1000 set/sets per month
Place of Origin: China (Mainland)
Supply Ability: 1000 set/sets per month
Multifunction precision 6 row seeder :
We supply multifunction precision 6 row seeder sowing machine is matched with tractor with more than 65 horsepower, one operation can complete stubble cleaning, fertilization, precision sowing and compaction and other processes.
The tractor 6 rows mechanical precision maize/corn planter machine adopt driving rotary type cleaning device, can effectively remove straw and stubble, which provide a good seedbeds for seeding and solve the problem of trench opener entanglement congestion.
The crop sowing mechanical planter with fertilizer equipped with finger-clip seed metering device to ensure sowing precision and efficient operation of the unit.
Parameters of multifunction precision 6 row seeder:
1. Model: 2BYF-6
2. Dimension: 1600X3300X1200 mm
3. Weight: 750 kg
4. Matched Tractor: 60~100 hp
5. Working width: 320 cm
6. Planting rows/fertilizing rows: 4/4
7. Row spacing: 40~60 cm
8. Seed metering device type: finger-clip type
Features of multifunction precision 6 row seeder:
1 . The maize planter with fertilizer adopt vertical rotary blade to clear straw and stubble , which avoid soil moisture loss caused by soil disturbance .
2 . The maize seed planter using large mould side box transmission, high speed operation is more stable, large diameter cutter shaft cleaning effect is better .
3 . The sowing legs and pressing wheels are equipped with the latest independent copying mechanism, which is free to adjust and adapt to a variety of operating environments .
4 . The no-till seeder equipped with pinch-type precision seed metering device to improve the sowing precision, the operating speed can be 5~7 km/h when the operating conditions be allow.
